Overview
Power inverters have become a staple in businesses and homes around the world due to intermittent brown and black-outs. AIMS Pure Sine Wave Power Inverters provide reliable transformation of DC power from a battery (such as the one in a car or RV) into AC power that can then be used to run lights, computers, printers, televisions, medical equipment* and a broad range of appliances. And when it comes to selecting an inverter, it’s helpful to know that AIMS Pure Sine Wave inverters represent the most technologically advanced, lightweight, compact and diverse inverters on the market to help ensure the widest use of applications. For over a decade, the AIMS’ Power Pure Sine Wave Power Inverters has consistently delivered the broadest range of sizes to accommodate virtually every power requirement.
Advantages of a pure sine inverter:
-Equipment runs more efficiently
-Motors run cooler
-Cleaner power
-Ideal for power tool chargers, laser printers, electric shavers, microwaves, variable speed motors, TV’s, medical equipment
To select the right inverter, first determine what devices you would need to run in the event of a power outage. Then, select the appropriate inverter that can carry the combined wattage requirements of these devices. Please see our tech support section for start up averages for all devices. At AIMS, you’ll discover our inverters range from 75 watts up to 50,000 watts – more than enough to power nearly every application imaginable.
Features
Features: MASTERPACK QUANTITY 6
- 1000 Watt continuous power
- Pure sine wave
- USB Port
- Dual AC receptacles
- On/off switch
- Over temperature indicator
- Overload protection
- Low battery voltage warning/shutdown
- High input voltage protection with automatic shutdown
- Over load indicator
- Short circuit protection
- Thermally controlled cooling fan
- AC output short circuit protection
- Instruction manual
- Free 1 year tech support
- 1 year warranty parts and labor
- Battery cables not included – 6AWG cables are recommended
Description
Specifications: MASTERPACK QTY 6. SAVE WHEN YOU PURCHASE OUR MASTERPACKS.
- Continuous output power: 1000 Watt
- Surge power capability (peak power): 2000 Watt
- DC input / operating voltage: 10 to 15 V
- Output voltage: 120 volts AC +/- 10%
- Output wave form: pure sine wave
- Output frequency: 60 Hz
- Battery low voltage alarm: 10.6 +/- 0.5 volts
- Battery low voltage shutdown: 10.0 +/- 0.5 volts
- Low battery voltage warning/shutdown
- No load power consumption: <1.4 DC amps
- DC amps – 83
- AC amps – 8
- Full load efficiency: 90%
- 1/3 load efficiency: 95%
- No load minimum operating temperature: 32 degrees F
- Full load maximum operating temperature: 104 degrees F
- AC output socket: dual type 2 -3 prong
- USB output: 5VDC, max 1 amp
- High input voltage protection: 15 volt
- Low input voltage shutdown: 10 volt
- Internal blade fuse protection
Dimensions:
- Unit weight: 5.3 lbs.
- Unit size: L x W x H: 11.53 x 5.51 x 2.91 inches
- Shipping weight: 7 lbs.
- Shipping size: L x W x H: 18 x 12 x 6 inches
Masterpack size: Quantity 6 15x15x14 38lbs
