24 VDC TO 12 VDC STEP DOWN CONVERTER – 10 AMP

$48.00 $43.00

Out of stock

Out of stock

SKU: CON10A2412 Category:

Overview

The AIMS Power 24 VDC to 12 VDC step down converter product line is non-isolated and should be used in negative ground systems (input and output have a common negative).  These converters are extremely efficient, compact and include all safety features.

The step-down DC-DC converter has an input voltage of 24 VDC nominal (range 20 VDC to 37 VDC) to a highly regulated output voltage of 12 VDC nominal at 30 Amps.  The AIMS power converters have CE EN61000-6-3:2007+A1:2011 and CE EN61000-6-1:2007 certifications.

Utilization:

  • Commercial equipment
  • Work trucks/van/buses
  • Marine
  • Security and lighting systems
  • Audio equipment

Features

Features:

  • 24 volt to 12 volt DC to DC converter
  • Green LED on front panel to confirm power on
  • Terminal block for DC input/output
  • Over temperature protection
  • Over load protection
  • DC input low battery shutdown
  • DC input high battery shutdown
  • DC output short protection
  • DC output over current protection
  • DC output over voltage protection
  • Aluminum case for optimal cooling
  • Instruction manual
  • Free 1 year tech support
  • 1 year warranty parts and labor
  • CE EN61000-6-3:2007+A1:2011
  • CE EN61000-6-1:2007

Video

Description

Specifications:

  • DC input voltage: 20-37 VDC
  • DC output voltage: 12.5-13.5 VDC
  • Output current: 10 amps
  • Output current max: 12 amps
  • Non-isolated
  • Conversion efficiency: >92%
  • DC input low battery shutdown: 18 +/- 1 volt
  • DC input high battery shutdown: >38VDC
  • DC input over current protection: 3 Amp fuse
  • DC input polarity protection: fuse protected
  • Over temperature protection: 150 +/- 5 degrees F
  • DC output short protection: yes
  • DC output over current protection: 12 amps
  • DC output over voltage protection: TVS Diode

Dimensions:

  • Unit weight: 1 lbs.
  • Unit size L x W x H: 5.91 x 3.39 x 2.2 inches
  • Shipping weight: 1 lbs.

Product manual: click here

Additional information

Weight 1 lbs
