3600 WATT MODIFIED SINE POWER INVERTER 12 VDC to 120 VAC ETL LISTED

$380.00

div#bread_checkout_button { background: #000; padding: 13px; background: #1c8195; border-radius: 24px; text-align: center; }


Add Remote

Add Cables

Add Fuse Kit

Overview

This 3600 Watt Modified Sine Inverter has a few unique features. First, the unit is ETL Listed and conforms to UL 458 Standards. The AIMS 3600 Watt also conforms to CSA Standard C22.2 No. 107.1-01. Canada. At AIMS Power, we listen to our customers and as a result, AIMS designed this 3600 Watt UL listed modified sine inverter with our customers in mind.

AIMS has produced a high quality unit that is also available in two other sizes 2000 and 3000 watts. It features a 20 amp GFCI outlet. That is exactly like the outlets you find in your bathroom and are able to be reset if they “pop” for safety.  This inverter also has a direct connect AC terminal block, which delivers the full 3600 watts to a single source. The compact design is lightweight and durable, taking up less space in your work environment.

Features

Features:

  • 3600 Watt max continuous power
  • Modified sine wave
  • Digital display
  • LED monitoring lights
  • Dual GFCI outlet
  • AC direct connect terminal block
  • Overtemperature protection
  • Overload protection
  • Thermal cooling fan operation
  • Internally fuse protected
  • AC output short circuit protection
  • Aluminum case for optimal cooling
  • Pre-slotted mounting plate
  • Instruction manual
  • Free tech support
  • 2 Year Warranty Parts and Labor
  • ETL Listed to UL 458 Standards and CSA 22.2

Video

Description

3600 WATT MODIFIED SINE POWER INVERTER 12 VDC to 120 VAC ETL LISTED

Specifications: 3600 WATT MODIFIED SINE POWER INVERTER 12 VDC to 120 VAC ETL LISTED

  • Continuous output power: 3600 Watt
  • Surge power capability (peak power): 7200 Watt
  • DC input / operating voltage: 10 to 16 V
  • Output voltage: 120 volts AC
  • Output frequency: 60 Hz +/1 .5 Hz
  • Battery low voltage alarm: 10.5 +/- 0.5 V
  • Battery low voltage shutdown: 10.0 +/- 0.5 V
  • No load minimum operating temperature: 25° F
  • Full load maximum operating temperature: 140° F (automatic shutdown)
  • Efficiency: 90%
  • No load draw: <1.4A
  • AC amps: 30
  • DC amps: 300
  • AC output socket type: dual GFCI and AC direct connect terminal
  • High input voltage protection: 15V
  • Low input voltage shutdown: 10V
  • Internal fuse protection
  • ETL Listed to UL458 Standards – CSA 22.2
  • Product size (L x W x H): 14.5 X 6.62 X 5.6
  • Weight: Unit: 8.38 lbs Boxed: 12 lbs
  • 2 Year warranty

Product Manual AIMS Power 3600 Watt POWER INVERTER – PWRINV360012120W

3600 WATT MODIFIED SINE POWER INVERTER 12 VDC to 120 VAC ETL LISTED

Additional information

Weight 12 lbs
