AIMS LITHIUM BATTERY 12V 100Ah LiFePO4

$799.00 $749.00

12V, 100Ah, no Depth of Discharge recommendation, >4000 charge/discharge cycles up to 8x more than GEL, AGM or lead,, replaces 12V AGM, Gel & Lead batteries. Not intended to use as starting batteries. Ideal for back up power in RVs, boats, recreation vehicles and off grid back up power systems. Uses the same space as a your existing 12V battery but much  lighter. Made for extreme temperatures. Maintenance free. Must use lithium battery charger (LiFePO4).

Add Battery Jumper Cable

Add Fuse Kit – ANL Inline

Add Lithium Battery Charger

Pay Over Time


Overview

AIMS Power introduces its new battery product line of LiFePO4 batteries. The LiFePO4 batteries maintain constant output voltage, providing more efficient power. This allows the cell to deliver virtually full power until it is discharged without harming the battery, and it can greatly simplify or even eliminate the need for voltage regulation circuitry. The battery has a much longer cycle life capacity, and is easier to maintain compared to other battery technologies. Built with a sophisticated Battery Management System including multiple safety protections. The LiFePO4 technology has better thermal and chemical stability, which improves battery safety and packed with power in a small and lightweight footprint. Easily uses the same space as your existing 12V battery and replaces lead acid, AGM or Gel battery applications in RVs, boats, commercial vehicles, off grid back up power and much more. 50Ah, 100Ah & 200Ah models available. Not intended to replace starting batteries.

More info on lithium batteries click here



The 50 and 100 amp can’t be delivered to Hawaii or Alaska. The 200 amp battery CAN be shipped to HI and AK.

Features

  • Extremely high number of charge/discharge cycles
  • > 10 Year lifespan with proper maintenance
  • No need to worry about depth of discharge
  • Wide operating temperature range
  • Unsurpassed high temperature performance
  • Green energy without metal contaminant
  • Low maintenance
  • High amp capacity
  • Stable output voltage
  • Little self-discharge
  • BMS safety protection
  • Convenient removable carry handle
  • Lightweight
  • 50, 100 & 200 Ah models available
  • Short circuit protected
  • Physical damage to battery case will not cause fire
  • Excessive thermal exposure will not cause a fire
  • Able to withstand over-charge/over-discharge without damage to the battery
  • Sophisticated Battery Management System (BMS)

Description

Electrical SpecificationsLFP12V100A
Nominal Voltage12.8V
Nominal Capacity (at .5C, 77°F)100Ah
Minimum Capacity (at .5C, 77°F)95Ah
Expected Cycle Life>4800 cycles w/1C charge and discharge rate, at 77°F, 80% DOD
Operating Specifications
Charge MethodSmart charger, constant current, constant voltage
Charge Voltage Range (Max 14.6V)14.4 -14.6V
Continuous Charge Current100A Max
Charge Temperature32° F to 113° F
Continuous Discharge Current100A Max
Peak Instant Discharge Current (10 secs)200A
Over Voltage Shutdown15.6 +/-.2V
Discharge Cut-off Voltage8V =/- .5V
Discharge Temperature-4° F to 149° F
Storage Temperature-4° F to 113° F
Self Disharge (stored at 50% SOC)< 3%/month
Watt hours1200 watt hours
Physical Specifications
Battery Dimensions13″L x 9″H x 6.7″W
Weight30.2 lb
Shipping Weight32 lb
Group Size31
Battery post size5/16″
BMS Operation
Over Charge ProtectionOver charge detection voltage:   3.9 +/- .05V
Over charge detection delay time:   .96 – 1.4s
Over charge release voltage:   3.80 +/-.05V
Maximum charge voltage:   3.65 +/-.05V
Over Discharge ProtectionOver discharge detection voltage:   2.0V +/- .05V
Over discharge detection delay time:   115-173ms
Over discharge release voltage:   2.3V +/- .10V
Over Current ProtectionOver current detection delay time:   9 +/- 2ms
Over current release condition:   Cut load
Polarity Reverse ProtectionYes
Short Circuit ProtectionYes
UPC840271004587
Warranty10 Yr Manufacturer Defect

DUE TO THE STRICT RULES OF THE US DEPT OF TRANSPORTATION, WE DO NOT ACCEPT RETURNS ON THIS PRODUCT. – We can’t deliver to Hawaii or Alaska. The 200 amp battery is the only battery we can ship to HI or AK.

MANUAL CLICK HERE
