PV Wire 10 AWG Custom Lengths & Ends Click to Select Options…

Description

TheInverterStore offers custom lengths and ends for the 10 AWG PV Wire. These are made to order and will ship same day if ordered by 1pm PST.  WE DO NOT ACCEPT RETURNS FOR CUSTOM CABLES. Make sure your custom cable is exactly what you need before placing your order.

AVAILABLE ENDS

• LUG 3/8″ DIAMETER
• MC4 MALE
• MC4 FEMALE
• BARE END

Wire Specifications:

• Cable is Red, not black
• Voltage rating: 600 V
• Tinned copper OD 2.59mm
• Temperature rating:
• 90 °C dry or wet
• 194 °F dry or wet
• Ambient temperature: > 25 years (TÜV)
  • – 40 °C up to + 90 °C
  • – 40 °F up to + 194 °F
• Max short circuit temperature: 250 °C, +482 °F
• Bending radius: ≥ 5 × outer diameter
• Structure:  75/0.30 TC
• Conductor:  ID    3mm
• XLPE Thickness:  .72 mm
• Jacket:  OD   6.4 mm
• Weight: 100ft  5.6 lbs
• Allow: Current  49.6A
• Conductor Resistance Ω/km:  3.59
• UL4703

This UL Listed 10 AWG PV Cable is used as an extension cable for connecting solar panels in parallel or series and connecting to solar charge controllers .
