Description
- Surge power capability (peak power): 1200 Watt
- DC input / operating voltage: 10 to 15 V
- Output voltage: 120 Volt AC
- Output voltage regulation: +/- 3%
- Output wave form: pure sine wave
- Output frequency: 60 Hz
- Battery low voltage alarm: 10.6 +/- 0.5 V
- Battery low voltage shutdown: 10.0 +/- 0.5 V
- Low battery voltage warning/shutdown
- No load power consumption: < .6 dc amps
- DC amps – 50
- AC amps – 5
- Full load efficiency: 85%
- 1/3 load efficiency: >90%
- No load minimum operating temperature: 5 degrees Fahrenheit
- Full load maximum operating temperature: 104 degrees Fahrenheit (automatic shutdown)
- AC Output Socket Type: dual Type 2 -3 prong
- High input voltage protection: 15V
- Low input voltage shutdown: 10V
- Internal blade fuse protection
- 2 Year Warranty
- Listed to UL 458 and CSA 22.2 standards
Dimensions:
- Unit weight: 3.68 lbs.
- Unit size: L x W x H: 8.39 x 5.51 x 2.91 inches
- Shipping weight: 5 lbs.
- Shipping size: L x W x H: 13 x 13 x 4.5 inches
