Description
Specifications: – Includes one year warranty.
- Continuous output power: 1500 Watt
- Surge power capability (peak power): 3000 Watt
- DC input / operating voltage: 19 to 32 V
- DC input: 24VDC
- Output voltage: 120 volts AC +/- 10%
- Output wave form: pure sine wave
- Output frequency: 60 Hz
- Battery low voltage alarm: 19.6 +/- 0.5 volts
- Battery low voltage shutdown: 19 +/- 0.5 volts
- Low battery voltage warning/shutdown
- No load power consumption: <.7 DC amps
- Intelligent cooling (the cooling fan will start running when the case temperature reaches 104°F)
- DC amps: 83
- AC amps: 12.5
- Full load efficiency: 90%
- 1/3 load efficiency: 95%
- No load minimum operating temperature: 32-104 degrees F
- Full load maximum operating temperature: 104 degrees F (storage 113F)
- AC output socket: Qty 3 type 2 -3 prong
- USB output: 5VDC, max 1 amp
- High input voltage protection: 15 volt
- Low input voltage shutdown: 10 volt
- Internal blade fuse protection
Dimensions:
- Dimension (L x W x H) 15.875 x 8.375 x 3.875 in.
- Unit weight: 10 lbs
- Shipping weight: 12 lbs
- Remote port for optional remote
Product manual: click here
