Description
5000 WATT MODIFIED SINE INVERTER 48 VDC TO 120 VAC – REFURBISHED INCLUDES ONE YEAR WARRANTY
Specifications: 5000 WATT MODIFIED SINE INVERTER
- Continuous output power: 5000 Watt
- Surge power capability (peak power): 10,000 Watt
- Dc input / operating voltage: 39 to 64 V
- Output voltage: 120 VAC +/- 10%
- Output wave form: modified sine wave with phase correction
- Output frequency: 60 Hz +/- 1 Hz
- Battery low voltage alarm: 40 +/- 0.5 V
- Battery low voltage shutdown: 38 +/- 0.5 V
- No load current: < 0.2 amps
- Full load efficiency: 90%
- 1/3 load efficiency: 95%
- No load minimum operating temperature: -15 degrees Celsius
- Full load maximum operating temperature: 55 +/- 5 degrees Celsius (automatic shutdown)
- AC Output Socket Type: quadruple Type 2 -3 prong
- AC Output Socket Type: quadruple Type 2 -3 prong
- High input voltage protection: 64 V
- Low input voltage shutdown: 38 V845
- Internal fuse protection
- UL maximum recommended per outlet 1500 Watt
- Battery terminals 1/8″
Dimensions:
- Unit weight: 15.6 lbs.
- Unit size L x W x H: 16 x 7.75 x 6 inches
- Shipping weight: 21 lbs.
- Shipping size L x W x H: 24 x 12 x 9 inches
Product Manual: click here
